Magnetic Tool Holders

Name: Magnetic Tool Holders
Brand: Ningbo Beilun Meank Magnetics Co.,Ltd.

Magnetic tool holders are c or u-shaped magnetic holders(holding magnets) that used for storing and organizing tools in workshops. That is a great design of magnet assembly for magnetic holding.

Magnetic tool holder composed of long U-shape steel shell and permanent magnets(NdFeB or Ferrite), its magnetism is permanent and never demagnetized. Due to the strip shape, it's also called magnetic tool bars or magnetic tool strips. The magnetic tool holders are widely used in car repair shops and any other machine repair workshop, even if for households.

Parameters Of Magnetic Tool Holder For Three Mounting Methods:

Magnetic Tool Holders

Model	L(mm)	L1(mm)	W(mm)	H(mm)	Weight(g)	Screw(pcs)	Force(kg)
MTHA-8"	200	150	24	13.5	301	2	8
MTHA-9"	230	180	24	13.5	333	2	9
MTHA-11"	280	230	24	13.5	407	2	12
MTHA-12"	300	250	24	13.5	450	2	14
MTHA-14.5"	370	320	24	13.5	545	2	16.5
MTHA-18"	450	400	24	13.5	673	2	21
MTHA-19"	480	430	24	13.5	705	2	22
MTHA-24"	600	550	24	13.5	897	2	30

Magnetic Tool Holders

Model	L(mm)	L1(mm)	W(mm)	H(mm)	Weight(g)	Screw(pcs)	Force(kg)
MTHB-8"	250	150	30	28	331	4	8
MTHB-9"	280	180	30	28	363	4	9
MTHB-11"	330	230	30	28	437	4	12
MTHB-12"	350	250	30	28	480	4	14
MTHB-14.5"	420	320	30	28	575	4	16.5
MTHB-18"	500	400	30	28	703	4	21
MTHB-19"	530	430	30	28	735	4	22
MTHB-24"	650	550	30	28	927	4	30

Magnetic Tool Holders

Model	L(mm)	L1(mm)	D(mm)	H(mm)	Weight(g)	Magnet(pcs)	Force(kg)
MTHC-8"	250	150	43	20	376	2	8
MTHC-9"	280	180	43	20	408	2	9
MTHC-11"	330	230	43	20	482	2	12
MTHC-12"	350	250	43	20	525	2	14
MTHC-14.5"	420	320	43	20	620	2	16.5
MTHC-18"	500	400	43	20	748	2	21
MTHC-19"	530	430	43	20	780	2	22
MTHC-24"	650	550	43	20	972	2	30

Attention: the maximum holding force has a relation with the contact area, the larger the contact area, the stronger the holding force.

Why Magnetic Tool Holders(magnetic Tool Bars) Are Used?

Magnetic tool holders provide a solution for organizing your tools, you can save much time on finding the needed tools by using a magnetic tool holder..

By using the magnetic organizer-magnetic toolbars, your workplace is no longer messy, they

It can help you make the most of your space. The strong magnetic toolbar will hold your tools firmly on the wall.

The maximum holding force of the magnetic tool holder is 30kg, which is enough for any single tool. For extra heavy-duty holding, you can use several magnetic tool strips together.

The Characteristics Of Common Magnetic Tool Holders(magnetic Tool Bars):

1, Size of common magnetic tool holders: 8" long,9" long,11" long12" long, 14.5" long,18" long, 19" long,24" long which can meet different needs.

2, To make it convenient to be mounted, self-tapping screws and plastic bottom seats are provided for the two ends of the magnetic tool holder.

Magnetic Tool Holders

3, To protect the magnet inside of magnetic toolbar, the steel house is a bit higher than the magnets. So as to avoid crash magnets when adsorb heavy tools.
